| Item No. 8022-3 Plastic Impulse Sprinkler
1)Size: 1/2" male thread
2)Pressure: 2.0-4.0kg
3)Flux: 0.62-0.90m³/h
4)Spraying radius: 9.0-10.5m
Material: engineering plastic, stainless steel 304
Nozzles are easy and convenient for cleaning or replacement even while operating
Full circle, 360 degrees rotation
The color of nozzle can be changed according to your requirement, such as red, green, blue, black etc.
UV protection available
The available nozzle size and related data is as below for reference:
| Nozzle |
Pressure(kg) |
Flux(m³/h) |
Spraying radius(m) |
| |
2.0 |
0.90 |
10.0 |
| Noz.4.0 |
3.0 |
1.15 |
11.5 |
| |
4.0 |
1.35 |
11.8 |
| |
2.0 |
0.78 |
10.0 |
| Noz.3.5 |
3.0 |
0.98 |
10.8 |
| |
4.0 |
1.15 |
11.2 |
| |
2.0 |
0.62 |
9.00 |
| Noz.3.0 |
3.0 |
0.76 |
10.0 |
| |
4.0 |
0.90 |
10.5 |
|
