Item No. RB-55B2 Plastic Impulse Sprinkler
1/2" male thread
Material: engineering plastic, stainless steel 304, brass
The size of nozzle available in 3.5mm and 4.0mm
Part circle, angle controllable
Adjustable from 25 degrees to 360 degrees
Round regulator and diffuseness to adjust screw
Keep good function in bad water
UV protection available
The nozzle size and related date is as below for reference:
Nozzle |
Pressure(kg) |
Flux(m³/h) |
Spraying radius(m) |
|
1.5 |
0.56 |
8.0 |
|
2.0 |
0.62 |
9.5 |
Noz.3.5 |
2.5 |
0.70 |
10.0 |
|
3.0 |
0.76 |
11.0 |
|
3.5 |
0.85 |
12.0 |
|
|
|
|
|
1.5 |
0.67 |
8.0 |
|
2.0 |
0.81 |
10.0 |
Noz.4.0 |
2.5 |
0.92 |
10.5 |
|
3.0 |
0.95 |
11.2 |
|
3.5 |
1.05 |
12.5 |
|
